Piranha Propellers 109D - D3 Replacement Blade Set 10 x 9 RH, 3-Pack
Piranha Propellers 109D - D3 Replacement Blade Set 10 x 9 RH, 3-Pack
Piranha Propellers
269 in stock
Couldn't load pickup availability
Piranha Propellers 109D - D3 Replacement Blade Set, 10 x 9 RH
Service the specified Piranha D3 configuration with three matching 109D composite replacement blades. Piranha’s blade guide lists a 10-inch assembled propeller diameter, 9-inch pitch and right-hand rotation. This packaged set supplies blades only, not a complete propeller, giving you the matching three-blade option instead of individual service blades.
D-series and E-series blades share the Piranha D/E-style modular hub system. Shared hub fit does not permit mixed blade configurations: all installed blades must match in pitch, blade style and series group. When changing pitch or style, replace the full blade complement rather than mixing D- and E-series blade styles on one hub. Confirm the engine-specific fit and blade clearance, especially on E-style applications.
Part Specifications
- Part Number: 109D
- Manufacturer Blade Group: D3
- Assembled Propeller Diameter: 10 inches
- Pitch: 9 inches
- Rotation: Right-hand (RH)
- Material: High-strength composite
- Package Quantity: Three matching replacement blades
- Hub Configuration: Shared Piranha D/E-style modular hub system; verify motor-specific fit and clearance
- Blade Matching: All installed blades must match in pitch, blade style and series group
Confirm Fitment Before Ordering
Use the parts diagrams available on our website to help identify the correct propeller components. Alternatively, send us your engine model and serial number by email, text or live chat, and we’ll confirm fitment before ordering. Include the Piranha hub code, existing blade reference and rotation. Shared D/E hub fit does not guarantee motor-specific clearance, so check the intended assembly carefully.
Additional Information
- Vendor: Piranha Propellers
- Part Number: 109D
- Kit Contents: Three matching replacement blades
For an individual replacement, see the Piranha 109D D3 10 x 9 RH single replacement blade.
Installation Notes
Refer to the applicable Piranha modular-propeller instructions and engine service manual for matched-blade selection, clearance checks, assembly and fastening requirements.
Frequently Asked Questions
Q: What is included in this 109D package?
A: Three matching composite replacement blades, not a complete propeller or hub assembly.
Q: Can D- and E-series blades use the same hub system?
A: Yes, they share the D/E-style modular hub system. Verify the specific engine and blade clearance, particularly on E-style applications.
Q: Can I mix pitches or D- and E-series blade styles?
A: No. All installed blades must match in pitch, blade style and series group. Change the full blade complement when switching pitch or style.
Q: What rotation does the manufacturer list for 109D?
A: Piranha’s blade guide lists right-hand rotation and the D3 blade group. Shared hub compatibility does not establish left-hand suitability.
Q: Do the 10 x 9 dimensions describe each loose blade?
A: No. They identify the assembled propeller diameter and pitch. Confirm the full reference and intended hub configuration before ordering.
